Welko EL 30 C Kaynak Plakalı Eşanjör
Welded Plate Heat Exchangers
Welded plate heat exchangers are specialized heat transfer devices composed of metal plates that enable efficient and effective heat exchange. These exchangers have a design where two or more fluids circulate independently within their own channels.
The working principle is quite simple: the first fluid enters through one channel, while the second fluid enters through another. As the fluids flow along the surfaces of the metal plates, heat transfer occurs through contact between the plates. Increasing the contact surface area between the plates enhances heat transfer and improves efficiency.
One of the key features of welded plate heat exchangers is that the plates are welded together. This welding process ensures the exchanger is leak-proof and prevents mixing of fluids. The tight seal allows the exchanger to operate safely and efficiently.
These exchangers have a wide range of applications, including industrial processes, chemical and petrochemical plants, power generation and distribution, HVAC systems, marine and high-speed trains, the food industry, and many other sectors. Their compact design allows for space-saving installations while providing high efficiency.
Technical Specifications
-
Minimum Temperature: -195 °C
-
Maximum Temperature: +220 °C
-
Design Pressure: 30–45 bar
-
Suitable for standard and high-pressure applications
-
Connection Types: Threaded, welded
-
Connection Size: 3/4" - 1/2" Straight
-
Brazing Materials: Copper and Nickel
