Unox Wafer Type Butterfly Valve with 220V AC Electric Actuator
What is an Electric Actuated Wafer Type Butterfly Valve?
An electric actuated wafer type butterfly valve is a type of valve designed to control the flow of liquids through a pipeline. It consists of a circular disc mounted on a shaft that passes through the center of the valve body. The disc can rotate around the shaft to open or close the flow of liquid through the valve. The electric actuation means the valve can be opened and closed using an electric motor rather than manual operation.
Wafer type butterfly valves are designed to be mounted between flanges using a wafer-shaped disc that is held in place by bolts between the flanges. This allows the valve to be easily installed without cutting the pipe or making other modifications to the piping system.
Where are Electric Actuated Wafer Type Butterfly Valves Used?
Electric actuated wafer type butterfly valves are typically used in applications where precise control of fluid flow is required, such as in industrial processes or the operation of power plants. They are also commonly used in applications requiring fast and reliable valve operation, such as emergency shutdown systems.
Application Areas
-
Heating, ventilation, and air conditioning (HVAC) systems
-
Water treatment and distribution systems
-
Mining industry
-
Shipbuilding and drilling facilities
-
Food and chemical industries
-
Firefighting systems
-
Handling of water, seawater, dust, gas, wastewater, and air
Product Features
-
Body: GGG40.3 Ductile Iron
-
Disc: Al-Br Aluminum Bronze
-
Shaft: SS 416 Stainless Steel
-
Temperature Range: -10ºC to 110ºC
-
Seal: EPDM
-
For products DN40, DN50, and DN65, a 30 Nm actuator is used.
