Pakkens Panel Mount Glycerin-Filled CL2.5 Manometer Q100 40 BAR
Pakkens Q100 Series Panel Mount Glycerin-Filled Manometer
The Pakkens Q100 series panel mount glycerin-filled manometer is designed for accurate and stable measurement in medium to high-pressure applications. With a measurement capacity of 40 BAR, this model’s glycerin-filled design reduces needle oscillation in vibrating environments, providing long-lasting and reliable performance.
Featuring an accuracy class of CL2.5, it offers ±2.5% measurement accuracy, providing sufficient precision for system monitoring. Its panel mount design is suitable for integration into control panels. The 100 mm diameter dial offers a large, easy-to-read display, enhancing operator convenience.
Technical Specifications
| Feature | Value |
|---|---|
| Model | Pakkens Q100 Panel Mount |
| Pressure Range | 0 – 40 BAR |
| Accuracy Class | CL2.5 (±2.5% accuracy) |
| Display Type | Glycerin-filled |
| Dial Diameter | 100 mm |
| Mounting Type | Panel mount (flush mount) |
| Connection Location | Rear connection |
| Connection Size | G 1/2” BSP (customizable) |
| Material | Typically stainless steel or optional brass |
| Operating Temperature | -20°C to +60°C |
| Protection Class | IP65 |
| Standard | EN 837-1 |
Advantages
✅ Reliable pressure measurement up to 40 BAR
✅ Glycerin filling offers vibration resistance and extended lifespan
✅ CL2.5 accuracy class ensures adequate precision for process monitoring
✅ Large 100 mm dial for easy readability
✅ Panel mount design ensures aesthetic and organized panel layout
✅ Rear connection suitable for panel installation
Applications
- Industrial control panels
- Pump and compressor systems
- Hydraulic and pneumatic lines
- Water treatment and distribution systems
- Heating and cooling (HVAC) installations
- General process applications
Note: CL2.5 class manometers are ideal for applications where high precision is not critical but durability and readability are prioritized.
