Pakkens Alttan Bağlantılı Gliserinli CL1,6 Manometre Q100 160 BAR
Pakkens Q100 Series 160 BAR Pressure Gauge
The Pakkens Q100 Series 160 BAR pressure gauge is designed to provide reliable and precise measurement in high-pressure systems. With a CL1.6 accuracy class, it delivers clear pressure readings with ±1.6% accuracy. Its glycerin-filled dial minimizes pointer oscillation in vibrating environments.
The bottom connection design allows easy integration into compact systems. The 100 mm diameter wide dial ensures easy readability of values. The fully stainless steel case and internal mechanism offer superior resistance against corrosion.
Technical Specifications
-
Dial Diameter: 100 mm
-
Connection Type: Bottom connection
-
Connection Size: G 1/2” BSP (custom sizes available upon request)
-
Pressure Range: 0 – 160 BAR
-
Filling Type: Glycerin (vibration dampening)
-
Material: Fully stainless steel case and mechanism
-
Accuracy Class: CL 1.6 (±1.6% deviation)
-
Operating Temperature: -20°C … +60°C
-
Protection Class: IP65
Applications
-
Compressor and pump systems
-
Industrial automation and process lines
-
Hydraulic and pneumatic applications
-
Water, steam, and gas installations
-
Chemical, petrochemical, and power plants
Product Advantages
✅ High-pressure measurement capacity (160 BAR)
✅ Vibration-resistant glycerin-filled dial
✅ Reliable measurement with CL1.6 accuracy
✅ Long-lasting fully stainless steel construction
✅ Large, easy-to-read 100 mm dial
✅ Easy installation with bottom connection design
