Pakkens Alttan Bağlantılı Kuru Tip Komple Paslanmaz Manometre CL1 Q100 2,5BAR
Pakkens Q100 Series Dry Type Manometer
The Pakkens Q100 series dry type manometer delivers high performance and durability in sensitive applications requiring low pressure measurement. With a 2.5 BAR measurement range, it ensures precise and reliable readings.
Its CL1 accuracy class (±1%) guarantees accurate and consistent data for critical process control. The all-stainless steel construction offers excellent corrosion resistance, making it suitable for harsh operating environments.
Being dry type, it provides quick and clear needle movement without the need for glycerin filling. The bottom connection design allows for easy installation in tight spaces, while the 100 mm wide dial ensures readability from a distance.
Technical Specifications
| Feature | Value |
|---|---|
| Model | Pakkens Q100 |
| Pressure Range | 0 – 2.5 BAR |
| Accuracy Class | CL1 (±1% accuracy) |
| Display Type | Dry (Glycerin-free) |
| Dial Size | 100 mm |
| Connection Type | Bottom connection |
| Connection Size | G 1/2” BSP (customizable) |
| Material | All-stainless steel (casing and internals) |
| Operating Temp. | -20°C to +60°C |
| Protection Class | IP65 |
| Standard | EN 837-1 |
Key Advantages
✅ Accurate pressure measurement up to 2.5 BAR
✅ CL1 accuracy class with ±1% precision
✅ Dry type mechanism offers quick, stable needle movement without glycerin
✅ Fully stainless steel body for long-term durability
✅ Large 100 mm dial ensures high visibility
✅ Bottom connection enables easy mounting in compact setups
Typical Applications
-
Low-pressure gas and liquid systems
-
Water treatment and distribution facilities
-
HVAC systems
-
Laboratory and process control applications
-
Food and chemical industries
-
General industrial processes
Note: Dry type manometers perform best in low-vibration, stable environments. For more demanding conditions, glycerin-filled models are recommended.
