Pakkens Alttan Bağlantılı Gliserinli CL1 Manometre Q100 4BAR
The Pakkens Q100 series glycerin-filled manometer is designed to provide precise and reliable measurement even in low-pressure ranges. Featuring the CL1 accuracy class (±1% accuracy), this model stands out with its glycerin filling that ensures more stable and readable needle movement, especially in vibrating environments.
With a 4 BAR measurement range, it enables highly accurate monitoring in low-pressure systems. Its bottom connection design allows easy installation in tight spaces or panel mounts. The large 100 mm dial offers clear readability in industrial settings.
Manometer Technical Specifications:
| Feature | Description |
|---|---|
| Dial Diameter | 100 mm (Q100) |
| Connection Type | Bottom connection |
| Connection Size | G 1/2" BSP (custom thread options available) |
| Pressure Range | 0 – 4 BAR |
| Filling Type | Glycerin-filled (vibration damping) |
| Accuracy Class | CL1 (±1% accuracy) |
| Material | Full stainless steel body and internal parts |
| Protection Class | IP65 |
| Standard | EN 837-1 |
| Operating Temperature | -20°C … +60°C |
Manometer Advantages:
✅ High accuracy for low-pressure (4 BAR) applications
✅ Vibration-resistant glycerin-filled gauge
✅ Durable, full stainless steel construction for long service life
✅ Clear and accurate measurement with CL1 (±1%) accuracy
✅ Easy readability with a 100 mm dial
✅ Flexible and easy installation with bottom connection
Applications:
-
Water pumps and hydrophore systems
-
HVAC and boiler systems
-
Industrial liquid and gas pipelines
-
Process monitoring and automation systems
-
Chemical, petrochemical, and food industry applications
-
Laboratory and R&D environments
