Pakkens Back Connection Dry Type CL1 Pressure Gauge Q100 0.6 Bar

The Pakkens Q100 back connection dry type CL1 pressure gauge provides precise and reliable measurement with a pressure capacity of 0.6 BAR. It is a durable and long-lasting pressure indicator designed for industrial applications.

Product Features

• Model: Pakkens Q100
• Type: Dry type (non-liquid filled)
• Connection Type: Back connection (rear outlet)
• Measurement Range: 0 – 0.6 Bar
• Accuracy Class: CL 1 (±1%)
• Case Diameter: Approximately 100 mm
• Connection Size / Type: Typically ½" G thread (rear outlet)
• Material: Metallic or steel alloy case; mechanism made of brass or copper alloy
• Dial / Pointer: Aluminum dial with high-contrast printing; pointer designed for precise readability
• Protection Class: IP41 or equivalent (protection against dust and water splashes)
• Ambient / Fluid Temperature: Typically between −20 °C and +60 °C
• Standard: Compliant with EN 837-1 technical standard

Applications

Pressure gauges with low-pressure ranges like this are commonly used in:

• HVAC and air conditioning systems (air ducts, fan outlets, etc.)
• Low-pressure gas lines
• Filter system outlets to measure filtration or pressure drop
• Systems requiring precise pressure control
• Laboratory or process monitoring applications
