Fantini Cosmi B12HN Prosestat 60-300Bar

What is a Prosestat?
Prosestats are pressure switches used for fluids and inert gases. They are suitable for controlling compressors, autoclaves, lubrication circuits, steam boilers, irrigation systems, and similar applications.

General Features:

• Precision element with stainless steel diaphragm, laser-welded

• Metallic frame

• Impact-resistant thermoplastic cover

• PVC cable gland outlet connections

• Female connection G 1/4 (17 mm wrench)

• Maximum temperature of the controlled fluid: 120 °C

• Acceptable ambient temperature for the pressure switch body: -35 ÷ 60 °C

• Storage and transport temperature: -35 ÷ 60 °C

• Unit weight: 0.44 kg

Electrical Features:

• Rated insulation voltage Ui: 415 V ~

• Continuous operating nominal current Ith: 16 A

Accessories:

• V0 self-extinguishing, impact-resistant thermoplastic G1/2 cable gland, code: 303298LA

• IP44 protection casing, code: 2593367
