Fantini Cosmi B12GN Prosestat 25-150Bar

What is a Prosestat?
Prosestats are pressure switches used for fluids and inert gases. They are suitable for controlling compressors, autoclaves, lubrication circuits, steam boilers, irrigation systems, etc.

General Features

• Stainless steel diaphragm with precision element, laser-welded

• Metallic frame

• Shock-resistant thermoplastic cover

• PVC cable gland output connections

• Female connection G 1/4 (17 mm wrench)

• Maximum temperature of controlled fluid: 120 °C

• Acceptable temperature for pressure switch body: -35 ÷ 60 °C

• Storage and transport temperature: -35 ÷ 60 °C

• Unit weight: 0.44 kg

Electrical Features

• Rated insulation voltage Ui: 415 V ~

• Continuous operating rated current Ith: 16 A

Accessories

• V0 self-extinguishing, shock-resistant thermoplastic G1/2 cable gland, code: 303298LA

• IP44 protective housing, code: 2593367
