Fantini Cosmi B12DN Prosestat 5-16Bar General Description:
The Fantini Cosmi B12DN is an adjustable pressure switch designed for fluids and inert gases. It is used for control and safety purposes in industrial systems, compressors, boilers, tanks, autoclaves, as well as in ventilation and lubrication circuits.
Fantini Cosmi B12DN Prosestat 5-16Bar Technical Specifications:
| Feature | Value |
|---|---|
| Scale / Adjustable Pressure Range | 5 … 16 bar |
| Adjustable Differential Pressure | 1 … 3.5 bar |
| Maximum Pressure (Sensor Element Tolerance) | 18 bar |
| Connection / Mounting Thread | G ¼ female, 17 mm wrench size |
| Protection Class (IP) | IP40 |
| Operating Temperature (Sensor / Environment) | Max. 120 °C for fluid; −35 … +60 °C for body and environment |
| Electrical Information | SPDT (changeable contact), 16 A continuous current. Nominal insulation voltage ~415 V |
| Material & Construction | Stainless steel diaphragm, laser welded; metal body; impact-resistant thermoplastic cover; PVC cable gland output. |
Fantini Cosmi B12DN Prosestat 5-16Bar Advantages:
-
Adjustable pressure setpoint allows control according to system needs.
-
Reliable construction and long service life due to high-quality materials.
-
Resistant to high temperatures and a wide range of environmental conditions.
-
Compliance with industrial standards (IP protection class, 16 A contact, etc.).
Fantini Cosmi B12DN Prosestat 5-16Bar Applications:
-
Steam boilers and heating systems
-
Autoclaves and pressurized tanks
-
Compressor systems
-
Ventilation and lubrication circuits
-
Pressure control and safety functions in other industrial systems
