Fantini Cosmi A04M (Manual) Electronic Contact Box

Electronic Contact Box General Features

The modular enclosure of the controller is made of impact-resistant thermoplastic material and is designed for side-by-side multiple installations.

ACCESSORIES

• UA03Y: waterproof enclosure IP65

• EA18-EA19-EA20-EA21: probes for conductive liquids

Electronic Contact Box Electrical Specifications

• Voltage between electrodes: 8 V~

• Detection range adjustable between 2 and 20 kΩ

• Maximum cable length: 800 meters, insulation 600 V~

• Insulation resistance: 100 MΩ

• Dielectric strength: 1,500 V~ for 1 minute

• Output with SPDT electromagnetic switching relay, voltage-free terminals

• Contact rating: 5A 230V AC-1
