Fantini Cosmi A03M (Automatic) Electronic Contact Box

Electronic Contact Box – General Features

The modular enclosure of the controller is designed for side-by-side multiple installations and is made of impact-resistant thermoplastic material.

ACCESSORIES

• UA03Y: Waterproof box IP65

• EA18, EA19, EA20, EA21: Probes for conductive liquids

Electronic Contact Box – Electrical Specifications

• Voltage between electrodes: 8 V~

• Detection range: adjustable between 2 and 20 kΩ

• Maximum cable length: 800 meters, insulation 600 V~

• Insulation resistance: 100 MΩ

• Dielectric strength: 1,500 V~ for 1 minute

• Output with SPDT electromagnetic switching relay, volt-free terminals

• Contact rating: 5A 230V AC-1
