The Danfoss KP35 pressure controller provides precise pressure control within a range of 0.2–7.5 bar. Commonly used in industrial applications, this pressure switch is noted for its high durability and reliable performance. It meets quality and safety standards with an IP30 protection rating and CE and RoHS certifications.

Pressure Switch

Product Details

• Gross Weight: 0.338 Kg

• Net Weight: 0.304 Kg

• Volume: 0.57 Liter

Pressure Switch Specifications

• Pressure Sensing Element: Diaphragm

• Pressure Connection Size: 1/4"

• Pressure Connection Standard: ISO 228-1

• Pressure Connection Type: G

• Connection Gender: Male

• China RoHS Compliance: Yes

• EEE Category: 5 small equipment (any external dimension ≤ 50 cm)

• Electrical Connection: Rubber cable gland

• Electrical Connection Size: 6–14 mm

• EN 60947 Electrical Features:

  • Pollution Degree: 3

  • Rated Impulse Voltage: 4 kV

  • Insulation: 400 V

  • Short Circuit Protection, Fuse: 16 A

• EN 60947 Cable Specifications:

  • Stranded with ferrule: 0.5–1.5 mm²

  • Stranded without ferrule: 0.7–2.5 mm²

  • Solid/Stranded: 0.75–2.5 mm²

• EU RoHS Compliance: Yes

• EU RoHS Exemption Clause: No

• Differential Pressure [bar] Max: 4 bar

• Differential Pressure [bar] Min: 0.7 bar

• Differential Pressure [psi] Max: 58 psi

• Differential Pressure [psi] Min: 10 psi

• In Scope of WEEE: Yes

• In Scope of WEEE and Contain Batteries: No

• Contact Rating:

  • AC15 = 10 A, 400 V

  • AC1 = 16 A, 400 V

  • AC3 = 16 A, 400 V

  • DC13 = 12 W, 220 V

  • LR = 112 A, 400 V

• Contact Function: SPDT

• Protection Class: IP30

• NEMA Protection Class: 1

Pressure Switch Limits

• Max. Test Pressure [bar]: 22 bar

• Max. Test Pressure [psig]: 319 psig

• Max. Operating Pressure [bar]: 17 bar

• Max. Operating Pressure [psig]: 245 psig

• Approvals: CCC, CE, CMIM, EAC, LLC CDC EURO-TYSK, LVD, PZH, RINA, RMRS, RoHS China, cULus UL353, cULus UL873, UKCA

• Ambient Temperature Range [°C] Max: 65 °C

• Ambient Temperature Range [°C] Min: -40 °C

• Ambient Temperature Range [°F] Max: 149 °F

• Ambient Temperature Range [°F] Min: -40 °F

• Ambient Temperature Note: 80 °C / 176 °F for max 120 min

• Other RoHS Documentation: Saudi Arabia RoHS

• Product Name Description: Pressure switch

• REACH Candidate List Substance: Lead (CAS no. 7439-92-1)

• Regulation Range: 6 inHg – 108 psig

• Regulation Range [bar] Max: 7.5 bar

• Regulation Range [bar] Min: -0.2 bar

• Reset Function: Automatic

• Type: KP35

• Product Accessories: Switch accessories

• Product Description: Pressure Switch

• Product Group: Switches and Thermostats
